With nearly 30,000 controllers installed worldwide, an existing network of 24 hour technical assistance and standby spare controllers ready to ship should a system need to be sent in for repairs, CMC are set up to offer outstanding service and support. WARDJet carries complete spare standby controllers that could be shipped to a customer in the event of a major issue. We have also negotiated with CMC that they carry all support for their products. So you can go direct to the manufacturer or give us a call. Simple. Easy. CMC controllers also feature remote access if permitted by your system manager. Detailed diagnostics can be done remotely from CMC offices along with software upgrades and repairs to some extent.

The BURNY® LCD-10 Plus is a completely integrated Control System featuring a PC-based numerical control, 3 axes drive amplifier and a comprehensive operators console. The BURNY® LCD-10 Plus provides the latest advances in CNC technology on a proven platform engineered to increase productivity and reduce costs.

Utilizing Windows® XP Embedded, the BURNY® LCD-10 Plus produces extremely precise and repeatable motion control and contains many features not found in other numerical controls such as true multitasking and DXF file conversion. Controllers are supplied with a network card and are ready to use for networking. Network cables, floppy discs and USB jump memory are not provided. Should additional options like fiber optic cables or wireless networking be needed, please contact us for a quotation. The BURNY® LCD-10 Plus also features 3 integrated axes with AC drives. Supported by BURNY's extensive staff of experienced inhouse engineers and service technicians, the BURNY® LCD-10 Plus is ready to perform for you today! As a premium member of the BURNY family of numerical controls, the BURNY® LCD-10 Plus continues a 35-year history of improving the productivity and increasing the profits of a worldwide customer base.

WARDJet / BURNY® LCD-10 Plus Controller Features

Process Control

This extremely powerful feature provides precise control over the settings used in waterjet and other cutting processes. Process Control results in consistent cut quality, the elimination of setup errors and produces optimum conditions for achieving maximum consumable life and superior cut quality.

Quick Plate Alignment

Quickly compensate for plate that is not aligned properly on the machine. The BURNY® LCD-10 Plus rotates the part program for proper placement on the true plate position. With a few simple screen prompts the BURNY® LCD-10 Plus rotates the part program for proper alignment with the plate. Virtually drop the plate and cut. This saves material and wasted time moving the plate into the correct cutting position.

Expandable Shape Library

Allows commonly used standard shapes to be designed right at the control. Touch the screen to input the required dimensions and follow a simple logical prompting process. Shapes are graphically displayed with dimension lines to assist the numeric entry process. A dynamic display draws the shape, which reduces guesswork. Now even complex shapes can be made consistently and accurately.

True Multitasking Environment

Increase operator productivity by performing many different tasks within the Windows® XP Embedded environment. Load a new part program, create or edit a part program, choose a new part program from the shape library, create or edit a program nest, check production messages, fill out productivity sheets, monitor consumables life - all at the same time and all while the machine is cutting!

Fast DXF File Conversion

The BURNY® LCD-10 Plus accepts direct downloads of CAD/CAM DXF files, which reduces the expense of third-party post processing software. Further, the BURNY® LCD-10 Plus can automatically assign Lead In/Lead Out positions or the operator can make these assignments manually.

Go To (Job Interrupt)

Interrupt the current cutting routine to cut a new part, move ahead multiple pierce points, recover from cut loss, recover from power loss, change torch consumables, interrupt a long nest, jump to the end of a part or nest, reverse cutting path - all quickly done at the touch of a button without losing machine position and without scrapping valuable material!

Bright Touch Screen Interface

With an industrial-grade touch screen, the BURNY® LCD-10 Plus provides an extremely user-friendly machine interface. The wide viewing angle and high resolution graphics generate a bright display even in the harshest shop floor environment, allowing operators to easily and effectively move through the menus and guide the cutting machine.

Full Color, Interactive Graphic Display

Eliminate dry runs and confirm the part program before cutting them with the BURNY® LCD-10 Plus' full color graphic display. View the cut path in real-time and monitor cut progress. Use the zoom tools to verify part spacing and eliminate wasted or unusable product.
