The Z-513 Waterjet

Z513 waterjet cutting system

Our Z-Series and R-Series waterjets are the highest accuracy machines we build.

WARDJet's Z-513 has been uniquely designed for overseas shipping. We created this machine with the largest cutting envelope possible to still have it fit into a shipping container fully assembled. This allows it to be shipped anywhere in the world with only minimal set-up upon arrival. Our overseas customers have enjoyed the benefits of the tank already being fully welded together when it arrives, as well as all of the accessory items being located within the tank. The Z-513 has a huge cutting envelope, yet our compact design has a footprint similar to many competitors 4' x 8' size waterjets.

How to Unload a Shipping Container from WARDJet

Our Z-513 is loaded with unique features you will only find on a WARDJet waterjet. For example, the Z-513 waterjet allows for a large variety of different sizes of materials to be cut with any number of cutting heads. By having an extra foot of space on our crossbeam, beyond the standard 12" of travel, the second Z carriage has room to be parked when not needed. This still allows the remaining head to have a full 12" of travel giving you incredible freedom as you choose how to use your machine.

Preparing your parts to be cut on the Z-513 is quick and easy. Most people are able to reach the middle of the table from the front and back of the unit. Different materials and parts can be loaded and unloaded anywhere on the table at the same time without having to climb onto it.

All WARDJet waterjets are built to allow unlimited length sheets or parts to be fed through the front and out the back of the waterjet. All Z-Series waterjets have an easy indexing system that makes it practical to move longer sheets through the machine.

The Z-513 comes with all the fantastic features that are standard with any Z-Series machine, including the freedom to choose which type or combination of grating and clamping system you want from our options. Following are the statistics for a standard Z-513:

Machine Dimensions Footprint 203.26" x 90.00" Gantry Only
Depth of tank 35"
Cutting Envelope X-Y Travel 64" x 145" with one carriage
Approximately 64" x 156" with two carriages
Software Advanced CAD/Cam Software Installed on customer's personal computer
Power Requirements Controller: Burny LCD-10 120V, 20 amps, X-Classic & XL 220V 30amps
30hp pump: 460V, 38 amp OR 230V, 76 amp (more info on pump requirements in the pumps section)
Air Requirements Minimum 40 psi for bulk feed hopper
  Minimum 20 psi for mini-hopper
  Minimum 80-90 psi for cutting heads
Water Requirements As a guide, a 50hp intensifier pump requires 1 gpm of water for cutting at 55,000 psi and 0-4 gpm for cooling water
Number of Z-Carriages Maximum 6
Mini Hopper One WARDJet Inc. patented mini-hopper per cutting head
Bulk Feed Hopper 1100 lb pressurized standard
Drive Mechanism Ball screw driven in all axes
Tolerances
Linear positional accuracy: +/- 0.003" (over 4' - 5' span)**
(tighter tolerances generally achieved)
Repeatability: ± 0.001" (over 4' - 5' span)**
(tighter tolerances generally achieved)
Speed From 0.01 ipm up to 500 ipm with an X-Series Controller
