HYPRECISION™ P-Series WATERJET PUMPS
Improving Productivity Through Prediction
HyPrecision pumps are the first waterjet pumps to incorporate predictive maintenance capabilities that substantially reduce maintenance costs and disruption caused by non-planned service. Equipped with standard features such as our proven Advanced Intensifier Technology™ (AIT) and a closed loop proportional pressure control, our new pumps offer you even more consistent cut quality while ensuring trouble-free operation and reliability.
EXCLUSIVE TECHNOLOGY
The Advanced Intensifier Technology™ (AIT) is the exclusive technology that facilitates longer maintenance intervals and rapid component replacement.
INCREASED PRODUCTIVITY AND REDUCED MAINTENANCE COSTS
Patented Seal Maintenance Technology™ extends seal life by up to 40%. The system monitors weepage and lets you know when it’s time to change intensifier seals – no more costly changing too soon or too late! This increases productivity, minimizes scrap, and saves time, aggravation, and money.
INCREASED PERFORMANCE
Standard on all HyPrecision Predictive pumps, closed loop proportional pressure control adjusts for ambient pressure and temperature, oil viscosity and hydraulic system wear parts, to deliver consistent quality at optimum cutting speeds.
IMPROVED RELIABILITY AND EASE OF SERVICE
With 10% fewer parts than earlier generations, new HyPrecision Predictive pumps include user-friendly features such as a color-coded junction box, electrical cable harnesses, quick-connect fittings, and an easy access bleed-down valve to make maintenance faster, easier, and less expensive.
IMPROVED SAFETY
Standard for “S” series pumps, clear window cover lets the operator see the intensifier and attenuator. Optional interlocks help prevent unauthorized access, and can be programmed to automatically stop the pump when opened. In addition, the seal maintenance technology’s drip tray helps keep the top deck – and the shop floor – clear of oil and water.













THE HEART OF EVERY HYPRECISION™ PREDICTIVE PUMP: ADVANCED INTENSIFIER TECHNOLOGY PROVIDING THE ULTIMATE IN WATERJET RELIABILITY
By rethinking the way the intensifier pump works, we were able to make it work harder, last longer and require significantly less service time.

THE HEART OF EVERY HYPRECISION™ PREDICTIVE PUMP: ADVANCED INTENSIFIER TECHNOLOGY PROVIDING THE ULTIMATE IN WATERJET RELIABILITY
By rethinking the way the intensifier pump works, we were able to make it work harder, last longer and require significantly less service time.
Model | Max Ouput Flow | Max Orifice | Max Pressure | Configuration | Power | Bleed-Down Valve | Motor Starter |
---|---|---|---|---|---|---|---|
P-Series 50S | 1.0 gpm | 0.014" | 60,000 psi | Single or Redundant | 50hp | Air | True Soft Start |
P-Series 60S | 1.2 gpm | 0.016" | 60,000 psi | Single | 60hp | Air | True Soft Start |
P-Series 75S | 1.5 gpm | 0.017" | 60,000 psi | Single or Redundant | 75hp | Air | True Soft Start |
Model | Max Ouput Flow | Max Orifice | Max Pressure | Configuration | Power | Bleed-Down Valve | Motor Starter |
---|---|---|---|---|---|---|---|
P-Series 50S | 3.79 lpm | 0.35 mm | 4137 bar | Single or Redundant | 37 kW | Air | True Soft Start |
P-Series 60S | 4.54 lpm | 0.40 mm | 4137 bar | Single | 44 kW | Air | True Soft Start |
P-Series 75S | 5.68 lpm | 0.43 mm | 4137 bar | Single or Redundant | 56 kW | Air | True Soft Start |
